78M05 - 7805 - (SMD TO-252/DPAK Package) - 5V Positive Voltage Regulator IC
- IC Package: TO-252 DPAK
- Type: Fixed Voltage Regulator
- Fixed output voltage: 5V
- Output current in excess of 0.5A
- Maximum DC input voltage: 35V, Dropout voltage: 2V
SKU: 78M05IC
Status: In Stock
| MRP.: |
|
| Price: | ₹12.00 excl. GST |
| ₹14.16 incl. GST | |
| You Save: | ₹0.84 (6%) |
| Inclusive of all taxes |
The 78M05 Voltage Regulator IC is fixed voltage monolithic integrated circuit voltage regulator and is designed for a wide range of applications. This regulator employ internal current limiting, thermal-shutdown and safe-area compensation, making them essentially indestructible. It can drive up to 0.5 A of output current.
Specifications
- IC Package: TO-252 SMD DPAK
- Type: Fixed Voltage Regulator
- Fixed output voltage: 5V
- Output current in excess of 0.5A
- Maximum DC input voltage: 35V, Dropout voltage: 2V
- Suitable for CMOS, TTL and the other digital IC’s power supply.
- Internal short Circuit Current Limiting
- Internal Thermal Overload Protection
